CCD Sensor
1/4 type Super HAD CCD
Effective Pixels
768 (H) x 494 (V)
Horizontal resolution
470 TV lines (Wide end)
Lens
10x Optical zoom, 40x with Digital Zoom,
f=3.1 mm (wide) to 31 mm (tele), F1.8 to F2.9
Digital Zoom
4x (40x with optical zoom)
Lens distortion
Less than 5 %
Angle of View (H)
6.6 degree (wide end) to 65 degree (tele end)
Min. Subject Distance
100 mm (wide end), 600 mm (tele end)
Min. Illumination
3.5 lux (F1.8)
S/N ratio
More than 50 dB
Pan/Tilt
Horizontal ± 100 degrees (Max speed 300 degrees/s),
Vertical ±25 degrees (Max speed 125 degrees/s)
(in 5/72 degrees increments)
Electronic shutter speed
1/4 to 1/10,000 sec.
White balance
Auto, ATW, One Push WB, Manual WB, 3200K, 5800K
Digital effects
Pastel/Nega/Sepia/B&W/Solarize/Mosaic/Slim/Stretch/Still/Flash/Lumi/Trail
AE control
Auto, Manual, Priority AE, Exposure compensation, Back Light compensation
Position preset
6 positions
Serial control
VISCA (RS-232C, 9600bps)
Storage temperature
-20 to 60°C; (-4 to 140°F)
Operating temperature
0 to 40°C
Power requirements /
Power consumption
DC 12 V
Max. 13.2W (at 12 Vdc)
Dimensions
113 (W) x 120 (H) x 132 (D) mm (4? x 4? x 5? inches)
Packing
Master Carton with 4 pieces
